Eelectron KNX presence detector. Circular area for detection within 12m diameter at a mounting height of 3m. Supplied with mounting details for flush mounting in, for example, suspended ceiling tiles and for flush mounting box. Access to programming button from the front for easy commissioning. On the back/top of the product there is a connection for KNX bus and 3 digital potential-free contacts. Example of use: 3 push buttons or magnetic contacts for windows, doors and folding walls. Built-in sensors: presence sensor, light sensor, temperature sensor, acoustic sensor, sound sensor, humidity sensor. Sensor technology: 1 Passive IR
Detection area (diameter) at different mounting heights:
Mounting height 2.5m = 10m
Mounting height 3.0m = 12m
Mounting height 3.5m = 13m
Mounting height 4.0m = 14m
AREA OF USE
Residence, shop, hospital, nursing home, hotel, office, conference room, warehouse, classroom, garage, etc.
PROJECT SAVINGS
Can be delivered pre-programmed and addressed with mounted label for individual address for faster commissioning process. Possibility of major financial savings for projects. Contact us for more information.
COLOR AND SHAPE
The product is available in black and white. For project-specific requests, the product can be delivered in any color. Contact us for more information.
FUNCTIONS AND PROGRAMMING
5 individually adjustable control channels/blocks, constant light regulator (independent of the 5 control channels), 2-stage dimming function, blocking function, brightness threshold, 12 freely configurable logic objects, virtual holder (virtual card reader for hotel rooms). Thermostat function for climate control with or without fan coil: Individual control for heating/cooling or combined automatic climate control with interlock and deadband. Control function for Tunable White “Circadian Daylight Rhythm”. Adjustable sensitivity for the presence sensor. Built-in temperature sensor. Hygrostat function with threshold setting, etc.
